Easy to handle, transport and assembly

Rack Flexible Flooring Pallet

The Multipurpose Flooring Rack

Rack Flexible Floor pallet is a logistically adapted Rack system that simplifies the installation and handling of our Flexible Floor. The Rack Concept consists of the wheelbase, frames, and beams. If you want a wheelbase, assemble the rack base on top of the wheelbase. Then frames and then beams are assembled after. The Rack concept is available in two, three or four heights. For 4 heights there is a rack of two plus two stack on each other.

The rack has a stable wheelbase with two steering wheels. You can choose between two or 4 steering wheels. You can handle the system with forklift both from the long and short sides. The Rack Concept is powder-coated. You can choose between RAL colors

THE MULTIPURPOSE FLOOR CONCEPT

Flexible Floor

Made from 100% recycled material

The Multipurpose Floor Concept

With Flexible Solid Floor System, you get a unique floor with several fields of applications. The Flexible Floor is ideal floors even in areas with high demands. It’s flexible and easy mounted ground protecting mats with high sustainability. The interlocking floor tiles are made from strong plastic and can be applied to all types of outdoor foundations, from sand and dirt to grass and soil.

Flexible Solid Floor is a completely modular floor concept, interchangeable and expandable and supports the weight of large trucks, forklifts, and other heavy equipment. Each tile is durable, easy to clean, slip-resistant, and contains UV additives for longer outdoor life.

The design makes modular flooring easy, and you still get the stability of a good strong floor. Its flexibility and strength make these ground protecting mats perfect for store units, pavilions and even to build temporary roads where the heavy vehicle can operate. Flexible Solid Floor is optimal to replace concrete in the fields. And of course, in all kind and sizes in MSU. It is unique to protect all kind of surfaces and is optimal to use.

Flexible Solid Floor is produced in 100% recycled material and shall remain in the economy for a long time as possible. We will achieve this by minimizing raw material consumption, waste, emissions, and energy consumption.

We call it Sustainable Development and Circular Economy.

Features and benefits

The Unique Design and Connection of Flexible Solid Floor provides the floor concept a tremendous strength and versatility, without the necessity of adding significant amounts of material or weight. When you start assembly and connect Flexible Solid Floor tiles with "over-underlay", you achieve a very great strength as the floor tiles support each other on 6 sides. You can assemble the floor system without any use of tools. There are no sharp edges on the floor tiles which make it smooth and safe to assemble. By using standard cleaning fluids and pressure washer it is very easy to clean. Flexible Solid Flooring System from IP-Group consists of three types: *Heavy Duty version with a load of 20 000 kg per. m2. *Light Duty with a load of 5 000 kg pr. m2. *SL Duty for Refugees Camp protecting against rain, cold and snow with a load of 1 000 kg pr. m2

Why use and choose Flexible Solid Floor?

*Replace concrete in the fields, *Portable and easy to handle, *1 person can assemble approx. 80-100 m² per. hour,  *No specialist handling required, *Quick to assemble and disassemble, *Produced in 100% recycled material, *Robust with no breakable parts, *Anti-slip and easy to clean, *Little to no ground preparation, *Installation on nearly all kind of terrain and surfaces, *Versatile, fits designs, curves around obstacles.

Please click to download Flexible Floor Conceptmanual

Please click to download Assembly Instruction

RENTAL OF FLEXIBLE FLOORING RACK

Ideal Solution for Rental Companies

Rack Flexible Floor pallet rental

PORTABLE, EASY TO HANDLE AND QUICK AND EASY TO INSTALL/REMOVE

CREATE TEMPORARY ROADWAYS

Cover a surface area of any shape or size

The Flexible Solid Floor System can be placed even on grounds with very low CBR values, e.g. clay, etc. The soft ground material will fill up the underneath rip design of the elements to further increase element stability. Important is that the ground is not sinking such as moor, swampland, etc. The floor tiles create a “bridging-effect” over the laid out ground.

The special shape and form of Flexible Solid Floor make it easy to be rapidly deployed and with little to no ground preparation. Create a stable, even surface over sand, gravel, mud, grass, asphalt, and other unstable surfaces quickly and efficiently. The rip structure on the underside of each floor tile distributes weight very effectively on uneven ground, ensuring a solid roadway for trucks, forklifts, and other heavy vehicles.

If there is a hole underneath the element may bridge it completely or bend into the whole depending on the size of hole and load. After the vehicle has passed over the element it will bounce back. The driveway should be closed also in width to have the best possible shear force performance especially if the driveway is going up and down in a longitudinal direction and eventually also has a transversal angle.
